This series is all about the balance of elements, and with the punchy tone of a 3D-scuplted, alder/maple-laminated body, timeless looks and the power of the Yamaha 3-band active/passive preamp. The 5-string version of the TRBX600 series provides the same power, tone and beauty as the four-string version, but delivers the low that will define your sound.
Neck
The TRBX neck design combines an ultra-comfortable profile with 5-piece maple/mahogany-laminated construction for outstanding stability and excellent tone.
Neck Joint
Developed through hundreds of hours of testing, the refined neck joint shape perfectly balances strength, vibration transfer and upper-fret access.
Headstock
Straight string pull from nut to machine head eliminates lateral tension, providing superior tuning stability and reducing overtones.
Nut
43mm (5-string) nut widths give fast, comfortable playability for any style.
Bridge
A high-mass, die-cast bridge efficiently transfers string vibrations to the body for a full, rich tone combined with excellent adjustability and road-tested durability. The 18mm spacing on the 5-string model offers outstanding playability for technical slap or finger styles.
Output Jack
The Yamaha metal, plate-mounted standard jack socket offers superior durability and easy maintenance.
Pickups
YGD H5 pickups are defined by a clean, open tone that’s perfectly matched with the flexibility of the active/passive preamp design. Their quad-pole piece design and alnico magnets give them the power to drive the active circuit and the sensitivity and subtlety to capture every nuance in passive mode.
Electronics (Active/Passive Selecter and Battery Alert)
TRBX600 models feature an audiophile-grade active/passive circuit for fine, tonal control and extreme flexibility. This advanced design offers a level-matched output, whether in passive or active mode, and tone-switching circuitry that seamlessly moves from treble control to master passive tone. High-quality, gold-plated parts are used for key signal chain contacts, providing increased conductivity and reliability, and the LED low battery alert installed on the back panel helps to prevent sudden power loss during performances.
Alder/Maple body construction
Flamed maple top
Maple/Mahogany 5-Piece Neck
Slim 1-11/16 " (43 mm) nut width
3-Band Active EQ with active/passive preamp
Battery Alert LED
Features
- Alder/Maple body construction
- Flamed maple top
- Maple/Mahogany 5-Piece Neck
- Slim 1-11/16 " (43 mm) nut width
- 3-Band Active EQ with active/passive preamp
- Battery Alert LED
Specifications
Neck
- Shape: C
- Wood: Mahogany with maple
- Neck joint: Bolt-on
- Scale length: 34 in.
- Truss rod: Standard
- Finish: Satin
Pickups
- Active or passive pickups: Switchable
- Pickup configuration: HH
- Neck: Double-coil alnico V
- Middle: Not applicable
- Bridge: Double-coil alnico V
- Brand: Yamaha
- Series or parallel: Series
- Active preamp: No
- Special electronics: None
Fretboard
- Material: Rosewood
- Radius: 10 in.
- Fret size: Medium
- Number of frets: 24
- Inlays: Dot
- Nut material: Urea
- Nut width: 1.69 in. (43mm)
Body
- Cutaway: Double cutaway
- Construction: Solidbody
- Body wood: Alder
- Top wood: Flamed maple
- Body finish: Gloss or Satin
- Orientation: Right handed
Controls
- Control layout: Volume, blend, high/mid/low with mini toggle (active/passive)
- Pickup switch: No
- Coil tap or split: No
- Tone switching: No
- Special switching: No
Hardware
- Bridge type: Fixed
- Bridge design: 5-Saddle adjustable
- Tailpiece: Not applicable
- Tuning machines: Die-cast
- Color: Chrome
Other
- Number of strings: 5
- Pickguard: No
- Special features: Pickups
- Case: Sold separately
- Accessories: None
- Country of origin: Indonesia
